High-Efficiency Monocrystalline Solar Panel | Optimized Dimensions for Versatile Commercial & Industrial Deployment
Engineered for maximum energy yield and installation flexibility, our 550W Monocrystalline Solar Panel delivers superior performance in a robust, industry-standard form factor. Meticulously designed solar panel dimensions ensure seamless integration into a vast array of projects, from expansive utility-scale farms to complex commercial rooftops. This product combines cutting-edge PERC cell technology with a durable, weather-resistant construction, offering a reliable and cost-effective power solution for B2B clients worldwide.
Product Overview
This premium 550W monocrystalline panel represents the pinnacle of modern photovoltaic engineering. It is built to provide exceptional power density and long-term reliability, making it an ideal cornerstone for solar installations where space optimization and return on investment are critical. The panel's carefully calibrated solar panel dimensions and weight are balanced to facilitate efficient handling, transportation, and mounting, reducing both logistical complexity and balance-of-system costs. It is certified to the highest international standards, ensuring global acceptance and performance peace of mind.
Key Features
- High-Efficiency MONO PERC Cells: Utilizes advanced monocrystalline Passivated Emitter and Rear Cell (PERC) technology for enhanced light absorption and superior conversion efficiency, exceeding 21.5%.
- Optimized Form Factor: The standardized solar panel dimensions (approx. 2279mm x 1134mm) are designed to maximize module count per pallet and per rooftop area, optimizing shipping density and installation layout.
- Enhanced Durability: Constructed with a robust anodized aluminum frame, high-transmission, anti-reflective tempered glass, and IP68-rated junction box to withstand harsh environmental conditions, including high wind, snow loads (5400Pa), and salt mist.
- Lower Degradation & Superior Warranty: Features a first-year degradation of ≤2% and an annual linear degradation of ≤0.55%, backed by a 12-year product warranty and a 30-year linear power output warranty.
- Improved Low-Light Performance: Exceptional energy generation during early morning, late afternoon, and overcast conditions, ensuring a more stable power output throughout the day.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Power (Pmax) | 550W |
| Cell Type | Monocrystalline Silicon (M10, PERC) |
| Module Efficiency | >21.5% |
| Solar Panel Dimensions (L x W x H) | 2279 ±3mm × 1134 ±3mm × 35 ±2mm |
| Weight | 28.5 kg |
| Frame | Anodized Aluminum Alloy |
| Front Glass | High-transmission, anti-reflective tempered glass (3.2mm) |
| Junction Box | IP68, 3 diodes |
| Power Tolerance | 0 ~ +5W |
| Operating Temperature | -40°C to +85°C |
| Max System Voltage | 1500V DC (IEC) |
| Fire Rating | Class A (IEC 61730) |
| Product Warranty | 12 Years |
| Linear Power Warranty | 30 Years (97% in Year 1, ≥85% in Year 30) |
Application Scenarios
The versatility afforded by its power class and standardized solar panel dimensions makes this panel suitable for a broad spectrum of commercial and industrial applications:
- Utility-Scale Solar Farms: High power density reduces the number of panels and land area required per MW, significantly lowering levelized cost of energy (LCOE).
- Commercial & Industrial (C&I) Rooftops: The panel's dimensions are optimized to fit common roofing materials and structures, maximizing energy generation per available square meter for factories, warehouses, and shopping malls.
- Agricultural & Aquacultural Projects: Ideal for agrivoltaics (solar sharing) and powering water pumps, aeration systems, and processing facilities.
- Large-Scale Distributed Generation (DG): Perfect for carport canopies, ground-mounted systems for schools, hospitals, and municipal buildings.
Advantages
- Maximized ROI: Higher efficiency and wattage directly translate to more kilowatt-hours generated per installed area, accelerating payback periods.
- Logistical Efficiency: Optimized solar panel dimensions and weight allow for more modules per shipping container and pallet, reducing transportation and handling costs per watt.
- Installation Flexibility: The standardized size is compatible with most mainstream mounting systems, simplifying design and speeding up installation timelines.
- Proven Reliability: Rigorous testing under extreme conditions ensures stable performance and minimal maintenance over decades, protecting your investment.
- Future-Proof Technology: Incorporates leading PERC cell technology with a track record of high performance and durability in the field.
Why Choose Us
As a tier-1 manufacturer with over a decade of expertise, we are committed to delivering more than just products. We provide comprehensive solar solutions.
- Vertical Integration: We control the entire production process from silicon ingots to finished modules, ensuring stringent quality control, cost stability, and reliable supply.
- Global Certification Portfolio: Our panels hold all major international certifications (IEC, UL, CE, TÜV, etc.), guaranteeing compliance and smooth customs clearance for projects worldwide.
- Technical & Logistics Support: Our in-house engineering and logistics teams provide pre-sales technical consultation, CAD drawings, and efficient global shipping solutions tailored to your project's specific solar panel dimensions and volume requirements.
- Strong Financial Health: Our robust financial standing backs our long-term warranty commitments, giving you absolute confidence in our partnership.
FAQ
1. Are the solar panel dimensions compatible with standard mounting systems?
Yes. The panel is designed with industry-standard frame profiles and hole spacing. It is compatible with the vast majority of mainstream fixed-tilt, adjustable, and tracking mounting systems from leading suppliers. We can provide specific compatibility sheets upon request.
2. How many panels fit on a standard 40-foot shipping container?
Given the optimized solar panel dimensions and standard palletization, approximately 680 to 720 modules (depending on packing method) can be loaded into a 40-foot HC container, maximizing shipping efficiency and reducing logistics costs per unit.
3. What is the significance of the 1500V system voltage?
A 1500V DC rating allows for longer string lengths, meaning you can connect more panels in a single series string. This reduces the number of combiner boxes, cables, and balance-of-system components required, leading to lower overall system cost and simplified installation for large-scale projects.
4. Do you provide technical drawings and 3D models for system design?
Absolutely. We provide comprehensive technical documentation, including detailed CAD drawings (DWG), 3D models (STEP), and datasheets that specify all critical parameters, including precise solar panel dimensions, mechanical load ratings, and electrical characteristics to facilitate accurate system design and engineering.
5. What is your minimum order quantity (MOQ) and lead time?
Our standard MOQ for this product is one 40-foot container. Lead times vary based on order volume and customization but typically range from 2 to 4 weeks for standard orders. We prioritize communication to provide accurate timelines for every project.
